VMC855H
BOCHI
The VMC855H vertical machining center is a high-speed, three-axis linear rail vertical machining center. It uses roller linear guides for the XYZ axes and features a Z-axis without counterweight balance structure. The machine is designed with a high cost-performance ratio and lightweight construction, offering high speed, high precision, stability, and reliability. It is suitable for milling, drilling, reaming, boring, tapping, and countersinking operations on parts such as valves, cams, molds, plates, and enclosures in industries including automotive, motorcycle, aerospace, mold making, communications, medical equipment, and instrumentation. This machine can be used for small to medium batch, multi-variety production, as well as for mass production in automated lines.
ITEM | Unit | VMC855H | |
Worktable | Dimension (W*L)（mm×mm） | mm×mm | 550×1000 |
T-slot（mm） | 5-18（H8） | ||
T-slot distance（mm） | ` | 90 | |
Max loading weight（kg） | Kg | 500 | |
Spindle | Spindle taper | BT40 | |
Spindle power（kW） | kW | 7.5/11（FANUC） | |
Spindle speed（r/min） | r/min | 8000 | |
Pull stud model | MAS 403 P40T-Ⅰ | ||
Travel | X axis | mm | X axis travel（mm） |
Y axis（mm） | mm | Y axis travel（mm） | |
Z axis（mm） | mm | Z axis travel（mm） | |
Process capacity | Distance between spindle center and column slide | mm | 810 |
Distance between spindle surface and worktable surface | mm | 185-885 | |
Processing range | Distance between spindle center and guide of column（mm） | mm | 610 |
Distance between spindle surface and worktable surface（mm） | mm | 100-700 | |
Feed（directly coupled） | Max. Feed speed（X/Y/Z） | mm/min | 10000 |
Rapid speed（X/Y/Z） | m/min | 48/48/32 | |
X、Y、Z axes motor power | kW | ≥1.8 | |
Tool magazine | Tool number | pcs | 24T disc type tool magazine |
Max. Tool weight | kg | 8 | |
Max. Tool size | mm | Φ80×300 | |
Others | Power source | kVA | 26 |
Machine tool gross weight（kg） | Kg | 5500 | |
Machine tool net weight（kg） | Kg | 5000 | |
Air source flow rate | L/min | 350 | |
Air pressure | MPa | 0.6-0.8 | |
Dimension（L*W*H） | mm | 2800×2400×2750（Standard） | |
Accuracy (GB/T18400) | Position accuracy (Full length) | mm | 0.01mm |
Repeat position accuracy (Full length) | mm | 0.008mm | |
