Introduction
TK50 is an easily-operated CNC lathe and driven by a main servo motor. This machine features an independent spindle structure and outputs infinite variable speed. Controlled by GSK control the lathe has two controllable axes. It can perform OD and ID turning, taper and arc turning, facing, metric and inch threading automatically. Suitable for chuck work and shaft work of multi-specification medium/small batches, especially those complicated and high accuracy workpieces.
Introduction
TK50 is an easily-operated CNC lathe and driven by a main servo motor. This machine features an independent spindle structure and outputs infinite variable speed. Controlled by GSK control the lathe has two controllable axes. It can perform OD and ID turning, taper and arc turning, facing, metric and inch threading automatically. Suitable for chuck work and shaft work of multi-specification medium/small batches, especially those complicated and high accuracy workpieces.
Specifications
Item | Unit | TK50 | |
Capacity | Max. swing over bed | mm | φ500 |
Max. swing over slide | mm | φ280 | |
Max. turning dia. | mm | φ500 | |
Max. work length | mm | 1100 | |
Max. turning length | mm | 1000 | |
Spindle | Spindle bore | mm | φ87 |
Spindle nose | ISO702/ⅠA28 | ||
Spindle speed | r/min | 30-2500 | |
Spindle rated/max. torque output | N.m | 286/354 (GSK control) | |
Turret | Rapid traverse (Max.) | m/min | X axis:6 Z axis:8 |
Lead screw pitch | mm | X-axis: 5 Z-axis: 6 | |
Capacity of turret | 4(standard)/6(optional) | ||
Max. section of tool | mm | □25×25 | |
Travel of carriage | mm | X axis: 275 Z axis: 1000 | |
Tailstock | Dia. of tailstock quill | mm | φ75(φ80 hydraulic tailstock) |
