CBK63 CNC lathe

  • CBK63
  • BOCHI

Introduction

The machine has 45 ° slant bed structure.The spindle,equipped with special frequency changing motor,uses 3-gear mechanical speed change can reach stepless speedchange.With large spindle power and swing diameter,the lathe ensures high rigidity and good reliability.


Specifications

Item

Unit

Specification

CBK63.1000

CBK63.2000

CBK63.3000

Capacity

Max. swing over bed

mm

φ630

Max. swing over slide

mm

φ445

Max. turning diameter

mm

φ500(4-station)/ φ400 (8-station)

Max. turning length

mm

1000/800

8-station

20001800

8-station

3000/2800

8-station

Max. bar diameter


Ф62

Spindle

Spindle bore

mm

φ84

Spindle nose


A1-11(manual chuck)/   A2-8(hydraulic chuck)

Spindle speed

r/min

20-210 (L) 50-525 (M) 155-1600   (H)

Main motor

kW

11 kW servo motor

Tailstock

Diameter of quill

mm

φ100

Standard/live spindle center   (MT No.)


5/4

Max. travel of quill

mm

150

Turret

Number of stations


4/8

Width of top rest of power   turret

mm

200×200

Standard tool section

mm

32×32

Carriage

X/Z-axis rapid traverse

m/min

8/8

X/Z-axis travel

mm

350/1000

350/1980

350/3000

Others

Power source

kVA

30

Dimension

mm

2720×1805×1885

3982×1805×1885

5052×1805×1885

Net weight

kg

5000

(incl. hydraulic unit)

5500

(incl. hydraulic unit)

7500

(incl. hydraulic unit)
